BT 3500

BT 3500

BT 3500

Automatic analyzer random access for clinical-chemistry and immunoturbidimetry computer controlled. Automatic - upon programmation - pathological results repetition with or without automatic dilution. Automatic - upon programmation - pathological results in the panic range repetition. Urgent tests in actual time (STATs). Sophisticated software for the system control. Software running under Windows 2000 Professional®. 40 on line tests mono or double reagent, refrigerated. 78 positions sample tray, programmable for samples, standards, controls and STATS.
Analyzer throughput: 360 test/h without ISE module. ISE module: 240 test/h. Two bar code readers for the positive identification of samples and reagents. Easy maintenance. No consumables.
Automatic washing of the reading cuvettes. Automatic - upon programmation - calibration of the I.S.E. module. Relation tests. Real pre-dilution up to 1:500. Clot Sensor: For Samples and Reagents.
Log file for data and performed operations.Vocal and on screen error messages.Touch screen monitor and wireless keyboard and mouse.

Brochure
Download Brochure

Catalog
Consumable Products

TECHNICAL SPECIFICATIONS

ANALYSES TYPE

Clinical Chemistry, Turbidimetric, DOA, I.S.E.

THROUGPUT BT3500

up to 360 Chem. Tests/hr + up to 190 ISE Tests7hr

THROUGHPUT BT3500S

up to 360 Chem. Tests/hr + up to 240 ISE Tests7hr

WATER CONSUMPTION

1620 ml/hr ± 20%

ISE MODULE BT3500

Na, K, Cl, CO2 indirect potentiometry serum & urine

ISE MODULE BT3500S

Na, K, Cl, CO2 indirect potentiometry serum, diluted urine

NUMBER OF REAGENTS

80 Total
40 using 50 or 80 ml vessels
40 using 10 or 20 ml vessels

REFRIGERATED REAGENT BAY

Yes

REACTION VOLUME

from 180 to 400 μl

SAMPLE VOLUME

from 1.8 to 100 μl

READING CUVETTES

45 non-disposable optical glass

SAMPLING ARMS

2, for Serum and Reagents

SAMPLE TRAY # OF POSITIONS

78 Total
62 Samples - 16 Standards and Controls

TEST MODES

Random Access, Batch, STAT

TEST DIRECTORY

Up to 500

CUVETTE TEMP. CONTROL

Peltier System OFF/30/32/37°C(±0.2°C)

VACUUM PUMP SYSTEM

External

PHOTOMETER

Solid State 10 Channel+reference channel
(340,380,405,436,480,510,546,578,630,700nm)

PHOTOMETER LINEARITY

Uo to 3.0 O.D.

PHOTOMETER SENSITIVITY

± 0.001 Abs.

DILUTER

2 - Long Life Ceramic 340 μl

DILUTER ACCURACY

± 0.1% f.s.

DILUTER RESOLUTION

0.1 μl

CLOT SENSOR

2 - one for each sampling arm

BAR CODE

2 - Reagent and Serum

BUILT IN QC PROGRAM

3 Levels Known, 3 Levels Unknown

MAINTENANCE

Software assisted

VETERINARY VERSION

OPTIONAL

COMPUTER

Internal Windows© PC

PROCESS ELECTRONICS

12 microcontrollers, I² CBUS protocol

DEVICES

DVD, HUB USB, HD>100 Gb

OPERATIVE SYSTEM

Windows© XP Pro or later

PERIPHERALS

OPTIONAL, on request printer & UPS

MONITOR

Color LCD 12"

TOUCH-SCREEN

Glass Protected, resistive

KEYBOARD & MOUSE

International

INTERFACE

Rs232+USB+LAN+VGA+Ethernet

REMOTE DIAGNOSTICS (MODEM)

Optional

POWER SUPPLY

Universal input 100/240 Volt, 50-60 Hz, 590 Watt, PFC

DIMENSIONS

Height - 27", Width - 40", Depth - 23" (68x100x58 cm)

WEIGHT

210 lb (95 Kg)

Rev. 10/2018

Features may change without notice
