Biotecnica Instruments

BT 642

BT 642

BT 642

Direct potentiometric measurement of ion analites in serum/urine 180 µL serum sampling. Throughput up to 180 tests per hour. Na, K, Cl, Li sensors. 3.2" TFT colour LCD display with touchscreen.

Brochure
Visualizza la brochure

Catalogo
Prodotti di Consumo

SPECIFICHE TECNICHE

CLINICAL

Direct potentiometric measurement of ion analites in serum/urine

180 µL serum sampling

Na, K, Cl, Li sensor

Throughput up to 180 tests per hour

Self calibrating

Single pack for reagent and waste

Embedded Thermal Printer

Quality Control and Statistics

Samples Tray (15 Samples + 1 Stat + 2 Controls)

SOFTWARE

Easy to use graphic and touch driven software interface

Upgrade software

Host interface

ELECTRICAL

3.2" TFT colour LCD display with touch-screen

16 bit 40 MIPS microprocessor with up to 512kB of flash memory

USB or RS232connection link for host control

Universal power supply 100-240 Vac and 24Vdc

Power consumption: < 40W

MECHANICAL

Dimension: 420x280x220 mm

Weight: 8Kg

Le caratteristiche possono cambiare senza avviso
